Manual Micro Dispensing Systems MDS 3010A-FA and MDS 3020A-FA
VTK-VS-BA-002 Revision B 23
Description of the RS232 commands:
1.
*ESR?
Description:
This command shows the last 10 error codes. The one shown on top is the latest. If you see
10 times 0, no error has occurred.
Example:
Input:
*ESR?
Result:
List with last 10 error messages
Return:
8 AUTORANGE ERROR
9 WATCHDOG TIMEOUT
0
0
0
0
0
0
0
0
2.
*IDN?
Description:
Returns the device descriptor; the description format: model, Firmware Rev.
Example:
Input:
*IDN?
Result:
micro dispenser LV,4061FA1-A
Return:
micro dispenser LV,4061FA1-A
3.
LCD?
Description:
Use this command to show the current text of the LCD signal.
Example:
Input:
LCD?
Result:
Right after turning on the system, our company name is shown.
Return:
Ready
4.
SYSTEM:KLOCK:OFF
Description:
This command unlocks the key panel.
Example:
Input:
SYSTEM:KLOCK:OFF
Result:
The key panel is unlocked.
Return:
OK
5.
SYSTEM:KLOCK:ON
Description:
This command locks the key panel so no one can change the pulse parameters unauthorized.
Example:
Input:
SYSTEM:KLOCK:ON
Result:
The key panel is locked.
Return:
OK
6.
TRIGGER:SET:?
Description:
The current pulse parameters will be displayed with this command. They come in this order:
Rising, Open Time, Falling, Needle Lift, Number of Pulses, Delay
All parameters relating to time are still shown as 1/10 ms (so 10 equals to 1 ms).
If the system is set to External-Control-Mode the Open Time will be displayed as “EXTERNAL”.
Example:
Input:
TRIGGER:SET:?
Result:
You see the current pulse parameters.
Rising: 10 equals 1 ms (ms = millisecond)
Open Time: 10 equals 1.0 ms
Falling: 5 equals 0.5 ms
Needle Lift: 80 %
Number of Pulses: 20
Delay: 8 equals 0.8 ms
Return:
10,10,0,5,80,20,8
7.
TRIGGER:SET:<Rising>,<Open Time>,<Falling>,<Needle Lift>,<Number of Pulses>,<Delay>
Description:
The current pulse parameters can be changed with this command. The trigger is not initiated.
All parameters relating to time are shown as 1/10 ms (so 10 equals to 1 ms).
Do only use positive integer numbers. If you want to use the External-Control-Mode enter
“EXTENRAL” for the Open Time. For saving use the command
EEPROM:CONF:SAVE:<memory cell>. For activating a dispense series with the defined
parameters use VALVE:OPEN.
Example:
Input:
TRIGGER:SET:10,10,5,80,20,8
Result:
The pulse parameters get the following values:
Rising: 10 equals 1 ms (ms = millisecond)
Open Time: 10 equals 1.0 ms
Falling: 5 equals 0.5 ms
Needle Lift: 80 %
Number of Pulses: 20
Delay: 8 equals 0.8 ms
Return:
OK
