LD-16 Door Operator - Modernization Integral Cab Header Installation
October 2021 - 88420 v.1.0
11
Single-Speed Side-Opening Doors Integral Cab Header Installation
(continued)
Figure 5 - Adapter Angle Installation (2 of 2)
C B
Clear Opening
Clear Opening
Door Lap
(standard door lap =
¾" )
6¼"
3¾"
(right-hand shown)
Top of Door Panel
qô°AáČZðáĦÔ°áÔûôǎ
• Small Hole/Slot = RH Opening*
• No Hole/Slot = LH Opening*
*From strike end of side opening
Use Push Nuts To Position
AáČZðáĦÔ°áÔûô
Push Nut
Push Nut
(right-hand shown)
ŐƽȚ
ŐƽȚ
ƜƭƂƇ"
