LD-16 Door Operator - Modernization Integral Cab Header Installation
October 2021 - 88420 v.1.0
13
Single-Speed Side-Opening Doors Integral Cab Header Installation
(continued)
Figure 7 - Door Operator Machine Installation (2 of 2)
Side-Opening Operator:
The Mounting Angle Toe is Facing the Motor
Front View
Top View
Almost Flush with Top of Operator
Mounting Bolt
