Separate Header Installation LD-16 Door Operator - Modernization
42 © Vertical Express
Separate Header Installation
(continued)
7. Install the CTS to the top of the junction box. See Figure 37.
8. Route the wiring harness from the junction box to the COP.
9. Install the junction box cover.
Figure 37 - CTS and Wiring Harness Installation
Install CTS and Wiring Harness
To Next Page
