New/Existing Car Door Panel Installation LD-16 Door Operator - Modernization
46 © Vertical Express
New/Existing Car Door Panel Installation
(continued)
8. Use a 6 mm T-handle Allen wrench to rotate the eccentrics and align the car door
panel with the return. See Figure 41.
9. Verify that there is
1
/
4
" clearance from the door to the top of the sill.
Figure 41 - Car Door Installation
T-handle Allen Wrench
