Chapter 2 Installation Of UPS Rack System And Parallel System 27
LIEBERT APM UPS Module And Parallel System 30kVA~150kVA User Manual
J2
J4
J3
X2
J2
J4
J3
X2
J2
J4
J3
X2
J2
J4
J3
X2
Dry contact and parallel
signal board
Rack module
system UPS 1
Dry contact and parallel
signal board
Rack module
system UPS 2
Dry contact and parallel
signal board
Rack module
system UPS 3
Dry contact and parallel
signal board
Rack module
system UPS n
Fig.
3-5:
Typical dual bus system (with LBS) consisting of two 1+1 parallel system
