30 Chapter 3 Installation Drawing
1
2
3
4
5
Fig.
4-3:
150kVA UPS module system, front view whit open door and back view without doors
1
2
3
4
Fig.
4-4:
Modular Battery Cabinet: front view with open door and back view without doors
1. Blanking plate
2. battery module
3. battery input
5. battery module CB
1.
power module
2. Battery module
3. Bypass module
4. Power input/output
5. Battery Module CB
