64 Chapter 9 Product Specifications
Dimensions,
W×D×H
mm 600×1100×1996
Number of Modules kVA 1 2 3 4 5
Weight, without battery modules kg 280 315 350 385 420
Power Module dimensions mm 440×132(3U)×650
Power Module weight kg 35
Battery Module dimensions mm 440×132(3U)×877
Battery Module weight kg 95
Battery Box dimensions mm 140×132(3U)×810
Battery Box weight kg 29
Modular Battery Cabinet dimension mm 600×1100×1996
Modular Battery Cabinet weight kg 250
Color N/A ZP7021
Protection Degree
IEC (60529)
N/A IP20 (finger-proof with front doors open or closed)
Tab.
9-4: UPS mechanical characteristics
Rated Power, kVA Unit 30kW 60kW 90kW 120kW 150kW
Rated AC Input Voltage
1
Vac
380/400/415 V(three-phase and sharing neutral with the bypass
input)
Input voltage range
2
Vac 305V~477V, 304V~228V (output derating lower than 70%)
Frequency
2
Hz 50/60Hz (range: 40Hz to 70Hz)
Power Factor kW/kVA, full load (half load) 0.99 (0.98)
Input power
kVA rated
3
(
maximum
4
)
5
33(37) 65 (74) 97(111) 129 (147) 161 (183)
Input current
Amps rated
3
(
maximum
4
)
6
47 (53) 93 (106) 139 (159) 185 (211) 231 (264)
THD THDI % < 4
Tab.
Tab. Tab.
Tab.
9
99
9-
--
-5
55
5:
::
:
Rectifier AC input (Utility)
1. Rectifier operates at any of the rated supply voltages and frequencies without further adjustment.
2. At 305V input mains, the UPS maintains the specified output voltage at rated load without discharging a previously
charged battery.
3. EN 62040-3 / 50091-3: at rated load and input voltage 400V, battery charged
4. EN 62040-3 / 50091-3: at rated load and input voltage 400V,
battery charging at maximum rated power.
5. Add 4.5kVA per each redundant module
6. Add 7A per each redundant module
Intermediate DC circuit
Rated Power, kVA Unit 30~150
Battery bus voltage Vdc
Nominal: 432V (VRLA Float charge is 540V) 36 jars of 12V VRLA
Range: 400V ~ 616V
Nominal 216=[36x6cell (12V)blocks]
Maximum 240=[40x6cell (12V)blocks]
Quantity of
lead-acid cells
Minimum 180=[30x6cell (12V)blocks]
Float Voltage V/cell (VRLA)
2.25 V/cell (selectable from 2.2 –2.3V/cell),
Constant current and constant
voltage charge mode
Temperature
compensation
mV/C° - 3.0 (selectable 0 to – 5.0 around 25°C or 30°C or inhibit)
Ripple Voltage % V float
≤
1
Ripple Current ~ C
10
≤
5
Boost charge
Voltage
VRLA
2.35 V/cell (selectable from 2.30-2.40V/cell)
Constant current and constant voltage charge mode
Boost Control -
- float-boost current trigger 0.050
C
10
(selectable 0.030-0.070)
- boost-float current trigger 0.010 C10 (selectable 0.005-0.025)
24 hr safety time-out (selectable 8-30 hr)
boost charge mode inhibit also selectable
