Vertiv Liebert CRV Plus - Electronic Expansion Valve (EEV); Electrode Humidifier

Vertiv | Liebert CRV+ | User Manual 6
1.3.4 Electronic Expansion Valve (EEV)
The EEV is designed for modulating control of the refrigerant mass flow with precision. The EEV collects
temperature and pressure signals at the same time to accurately regulate the refrigerant flow. The EEV's
wide operating envelope also lowers down the condensing pressure, thereby resulting in significant
energy savings.
 Designed for modulating control of the refrigerant mass flow with precision
 Ensures effective control on super-heating at t
he end of the evaporator
 Better low load capacity
 Designed for easy Installation-and-Service
Figure 1-7 depicts the image for the EEV used in the CRV+ Series:
Figure 1-7 EEV
1
.3.5 Electrode Humidifier
The Electrode humidifier helps to maintain constant humidity in test chambers and is quite efficient
in small-and medium-load applications.
Figure 1-8 depicts the image of an Electrode Humidifier:
Figure 1-8 Electrode Humidifier
