Mechanical Installation
3.4. Charging Refrigerant and Adding Lubricant Oil
3.4.1. Charging Refrigerant
The Liebert® CRV4 air-cooled series air conditioner is charged in the factory with 2 bar nitrogen for shipping.
Table 3-5, Table 3-6 and Table 3-7 are the standard refrigerant charge for outdoor (Vertiv™ Liebert® LSF/
Vertiv™ Liebert® LVC) and indoor units respectively.
Table 3-5 Refrigerant Charging Amount of the Liebert LSF Outdoor Unit (unit: kg)
Outdoor Unit Model LSF38 LSF42 LSF52 LSF62 LSF76 LSF85
Recommended charging amount 3.93 4.12 5.12 5.86 6.72 7.9
Table 3-6 Refrigerant Charging Amount of the Liebert LVC Outdoor Unit (unit: kg)
Outdoor Unit Model LVC088 LVC106 LVC140 LVC152 LVC170
Recommended charging amount 4.12 5.12 5.86 6.72 7.90
Table 3-7 Refrigerant Charging Amount of the Indoor Unit (unit: kg)
Indoor Unit Model CR025 CR035 CR045
Standard charging amount 2.47 3.12 3.44
The recharged amount of the refrigerant is calculated using the following formula:
Refrigerant relling amount (kg) = Recommended refrigerant charging amount of outdoor unit + recommended
refrigerant charging amount of indoor unit + refrigerant charging amount of per meter liquid pipe (kg/m) × total
length of liquid pipe (m)
Refer to the Table 3-8 for the refrigerant recharging amount of per meter liquid pipe for dierent ODs:
Table 3-8 Amount of Refrigerant per Unit Length of Liquid Pipe
Liquid Pipe
OD (mm)
Refrigerant Recharging Amount
of per meter Liquid Pipe (kg/m)
Liquid Pipe
OD (mm)
Refrigerant Recharging Amount of
per meter Liquid Pipe (kg/m)
12.7 0.107 22 0.321
16 0.174 25 0.431
19 0.245 28 0.517
For the refrigerant charging method, refer to Section 5.2.2 Commissioning Procedures.
