3.3 Pump Packages
The planning dimensions, electrical power-supply requirements, piping connections, and electrical connections are
described in the submittal documents included in the Submittal Drawings Contents on page65.
The following table lists the relevant documents by number and title.
Document Number Title
DPN000329 Pump Electrical Power Data and Piping-connection sizes.
DPN000278 Single-pump Piping connection locations and dimensional data
DPN000328 Dual-pump Piping connection locations and dimensional data
Table 3.4 Drycooler Pump Drawings
Figure 3.1 Pump curve, 60 Hz
NOTE: Higher-capacity pumps are available. Please contact your local sales rep for more information.
Vertiv | Liebert® Drycooler Installer/User Guide
14
