4.5 Preparing 1 to 4 Fan Drycooler forMovingandInstallation
The following procedure is one recommended method for removing a unit from the shipping skid. Other methods may be
used, provided that they are safe for personnel, the unit and equipment.
1. Attach legs to the unit at indicated locations, using the fasteners provided with the legs, Figure 4.3 below.
• Recommended tools for attachment is a 5/8” socket and ratchet.
• More legs may be available for installation than are shown. This will depend on the unit type and number
of fans. Refer to the appropriate planning-dimensions drawing in Submittal Drawings Contents on
page65, for the number of legs on your unit.
Figure 4.3 Attaching Legs to 1 to 4 Fan Drycoolers
