Vertiv Liebert Drycooler - Standard Drycooler Piping Connection Sizes and Internal Volume

Model #
No. of Internal Coil Circuits No. of Fans
Internal Volume,
gal. (L)
No. of Inlets/Outlets
Inlet & Outlet Connection Size
ODS Copper, in. IDS Copper, in.
033 4*
1
1.2 (4.6) 1/1 1-3/8 —
069 4, 8* 2.4 (9.2) 1/1 1-3/8 —
092 6, 12*, 16 3.7 (13.9) 1/1 1-5/8 —
109
8
4.9 (18.6)
1/1 1-3/8 —
16* 1/1 2-1/8 —
112
8
5.8 (22.0)
1/1 1-3/8 —
16*, 26 1/1 2-1/8 —
139 8, 16*
2
4.8 (18.2) 1/1 2-1/8 —
174 8, 16*, 24 6.9 (26.2) 1/1 2-1/8 —
197
8 9.0 (34.0) 1/1 1-3/8 —
16*, 32 9.0 (34.0) 1/1 2-1/8 —
225 16, 26* 11.1 (42.1) 1/1 2-1/8 —
260 16, 24*
3
10.0 (37.9) 1/1 2-1/8 —
310 16, 32* 13.1 (49.6) 1/1 2-1/8 —
350
16, 32*
19.4 (73.3)
1/1 2-1/8 —
48 1/1 2-5/8 —
352 16, 24*
4
13.1 (49.6) 1/1 2-1/8 —
419 16, 32* 17.4 (65.9) 1/1 2-1/8 —
466 26
22.0 (83.3)
1/1 2-1/8 —
466 40* 1/1 2-5/8 —
491
16, 32
26.3 (99.6)
1/1 2-1/8 —
48* 1/1 2-5/8 —
620 32, 64*
6
27.0 (102.2) 2/2 — 2-1/8
650
40, 52*
33.0 (124.9)
2/2 — 2-1/8
80 4/4 — 2-1/8
700
32, 64*
40.0 (151.4)
2/2 — 2-1/8
96 4/4 — 2-1/8
790 32, 64*
8
35.0 (132.5) 2/2 — 2-1/8
880
52
44.0 (166.5)
2/2 — 2-1/8
80* 4/4 — 2-1/8
940
32, 64
52.0 (196.8)
2/2 — 2-1/8
96* 4/4 — 2-1/8
* = Standard Circuiting
Table 5.3 Standard Drycooler Piping Connection Sizes and Internal Volume
