Model # No. of Internal Coil Circuits No. of Fans
Internal Volume,
gal. (L)
No. of Inlets/Outlets
Inlet & Outlet Connection Size
ODS Copper, in. IDS Copper, in.
040 4, 8*
1
2.4 (9.2) 1/1 1-3/8 —
057
12*
3.7 (13.9)
1/1 1-5/8 —
16 1/1 2-1/8 —
060
8
4.9 (18.6)
1/1 1-3/8 —
16* 1/1 2-1/8 —
080 8, 16*
2
4.8 (18.2) 1/1 2-1/8 —
111 16*, 24 6.9 (26.2) 1/1 2-1/8 —
121 16*, 32 9.0 (34.0) 1/1 2-1/8 —
158 16, 24*
3
10.0 (37.9) 1/1 2-1/8 —
173 16, 32* 13.1 (49.6) 1/1 2-1/8 —
178
16, 32*
19.4 (73.3)
1/1 2-1/8 —
48 1/1 2-5/8 —
205 16, 24*
4
13.1 (49.6) 1/1 2-1/8 —
248 16, 32* 17.4 (65.9) 1/1 2-1/8 —
347 32, 64*
6
27.0 (102.2) 2/2 — 2-1/8
356
32, 64*
39.3 (148.8)
2/2 — 2-1/8
96 4/4 — 2-1/8
453 32, 64*
8
35.0 (132.5) 2/2 — 2-1/8
498
32, 64
52.0 (196.8)
2/2 — 2-1/8
96* 4/4 — 2-1/8
* = Standard circuiting
Table 5.4 Liebert Quiet-Line™ Drycooler Piping Connection Sizes and Internal Volume
