Liebert

PDX, EconoPhase Version - UM - 265133 - 29.08.2019

10.5 - EC fan replacement

WARNING!

There is a risk of the fans and panel falling down and causing an injury during the replacement operation.

Due to the weight of the fans (approx. 35 kg) and the panel (up to 25 kg), two technicians are required to carry out the fan

replacement.

BEFORE COMMENCING, ALWAYS CUT ALL THE ELECTRIC SUPPLY CIRCUITS ON THE MACHINE OFF.

Only properly trained and qualied personnel should work on this equipment.

How to remove the fans

Remove the front panel (or a grid) to get access to the fan bays (see pictures below).

Note:

• Downow Down - remove oor panels positioned in front of the unit to get access to the fan section frontal grid. Remove any

obstacles in front of the fans to allow the fan extraction (e.g. the raised oor structure, piping)

Downow Up Downow Down

Downow Up

1) Disconnect thefan electrical cablefromthe

connector.

2) Remove the2frontscrews“a” from thefan

support (one screwoneachsideofthe sli -

ding bars)

3) Loosen the2rearscrews“b” of thefan sup-

port (one screw on each side of thesliding

bars)

4) Slide down th efan by pullingthe handle.

5) Remove completely the2screws “b”onthe

back of thefan.

6) Pull thehandleto slide thefan outofthe bay
