Digit 8 - Airow
L = Premium Fan Module
Digit 9 - Main Power Supply
3 = Single 400V / 3ph / 50 Hz + N
Digit 10 - Cooling System
X = Dual Circuit Digital Scroll R410A with EEV
Digit 11 - Humidication
0 = None
H = Infrared Humidier
U = Ultra Sonic Humidier
S = Electrode Humidier
Digit 12 - Microprocessor Control
2 = Inner Display only T sensor
3 = Inner Display TH sensor
U = Small Cold re display T sensor
B = Small Cold re display TH sensor
C = Large Cold re display T sensor
D = Large Cold re display TH sensor
Digit 13 - Heating & Re- Heating
0 = None
1 = Electric heating Std Capacity
2 = Electric heating High Capacity
Digit 14 - Air Filter E󰀩ciency
1 = F5 (EU5) dust spot
3 = F5 (EU5) dust spot + Clogged Filter
Digit 15 - Condensing Control
1 = Air Cooled or Water cooled with Standard Pressure, 2 way MBV
Digit 16 - Colour
1 = Black Vertiv RAL 7021
Digit 17 - High Voltage Option
T = Dual Power Supply parallel + Magnetic circuit breaker for 10A
three phases
U = Dual Power Supply Alternate with ATS + Magnetic circuit
breaker for 10A three phases
Digit 18 - Package Option
H = Predisposition for damper
L = Predisposition for plenum installation
Digit 19 - Monitoring
N = No IS Housing
0 = No Card
C = Sitescan Monitoring through INTELLISLOT IS-485EXI
P = MODBUS, BACnet, SNMP, Web through IS-UNITY card
Digit 20 - Sensors
0 = None
Digit 21 - Packaging
P = PLP And Pallet
C = PLP and Wooden Crate
S = Seaworthy
Digit 22 - Special Requirements
A = Standard Vertiv
X = Special Vertiv
Model Nomenclature / Digit Numbers
1
8 9 10 11 12 13 14 15 16 17 18 19 20 21 22
65432
P X
Digit 6
Air Discharge
D Downow Up
E Downow Down
Digit 7
System Type
P Air Cooled + predisposition for
pumped refrigerant economizer
Digit 1 and 2
PX Liebert
®
PDX
7
Digit 3, 4 and 5
Unit Model
