E.1 Kit Legs E.2 Baseframe
Legs kit can be supplied on request to support Liebert
®
PDX when
installed with a raised oor. The legs are xed with the unit frame
and allow to support the unit at di󰀨erent height, three kits are
available with di󰀨erent height: adjustable in the range: h1 30 - 370
mm; h2 370 - 570 mm; h3 570 - 800 mm.
A base frame can be supplied on request to support Liebert
®
PDX
when installed with a raised oor. The frame could be regulated
with a height from 120 mm to 800 mm and the unit is xed on it.
E.3 Fresh air module
Downow
PX082
…
120
The fresh air kit, optional, has a G3 class lter installed on the
intake side of the fan and is connected to the PDX unit with a 100
mm diameter plastic duct.
As the fresh air intake is positioned close to the fan suction, it will
easily mix with the recirculation air.
E.4 Vertical ow extension hood
An extension hood can be supplied on request and can be installed
on top of the unit. It is available with di󰀨erent height:
500 mm; 600 mm; 700 mm; 800 mm; 900 mm. It has the same
design as the unit and consists of sandwich panels lined with
non-ammable insulation material of class 0 (ISO 1182.2), density
30 kg/m
3
.
Note:
In downow units it is required a ange 50 mm high to connect the
extension hood to the unit (see E.10).
