Vertiv Liebert PEX4 Series User Manual

Vertiv | Liebert PEX4 | User Manual 3
Product Overview
1.3. Model Nomenclature
Table 1-1 Liebert PEX4 Model Nomenclature
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25
P 1 0 6 0 D A 1 3 8 0 9 0 2 E 1 D 0 0 N C E 0 4 0
Digit 1,2 Product Model Digit 18 Installation Option
P PEX4 L Air-Cooled, Long pipe> 30 m
Digit 3 Net Cooling Capacity kW C Low Temp Kit
0-9 Nominal Net Cooling Capacity - kW
B Low Temp Kit+Long Piping
Digit 4 Net Cooling Capacity kW Digit 19 Monitoring
0-9 Nominal Net Cooling Capacity - kW 0 RS485
Digit 5 Net Cooling Capacity kW S SIC Card
0-9 Nominal Net Cooling Capacity - kW
Digit 20 Sensor
Digit 6 Air Discharge
N Supply Air Temp Sensor
U Upflow
A Supply Air Pressure Sensor
D Downflow
F Smoke & High Temp Sensor
Digit 7 System Type H High Temp Sensor
A Air Cooled
S Smoke Sensor
Digit 8 Airow 1 Supply Air Pressure & Smoke
1 EC Plug Fan – Standard Static
2 Supply Air Pressure & High Temp
Digit 9 Power Supply 3 Supply Air Pressure & Smoke & High Temp
3 380 V to 415 V, 3 Ph+N~50 Hz/ 60 Hz
4 Supply Air Temp & Smoke Sensor
Digit 10 Cooling System 5 High Temp & Supply Air Temp Sensor
8 R-410a EC Scroll Compressor, Single Circuit
6 Supply Air Sensor & Supply Air Temp Sensor
9 R-410a EC Scroll Compressor, Dual Circuit
7 High Temp & Supply Air Temp Sensor & Smoke Sensor
Digit 11 Humidication 8 Supply Air Sensor & Supply Air Temp & Smoke Sensor
0 None
9 Supply Air Pressure & High Temp & Supply Air Temp Sensor
H Infrared Humidication
B
Supply Air Pressure & Smoke & High Temp & Supply Air
Temp Sensor
S Electrode Humidication
Digit 12 Display Digit 21 Packaging
9 9-Inch HMI
P Packaging – Standard Cardboard And Wooden Pallet
Digit 13 Re-Heating
C Packaging – Wooden Crate Export
0 None
Digit 22 Special Requirements
1 Electrical Heating Std. 1 Stage A SFA – None
2 Electrical Heating Opt. 2 Stage
E For Export
Digit 14 Filtration Digit 23 Order Identier
2 G4 (EU4) 0 Standard ESP
3 F5 (EU5) 1 High ESP 50 Pa
Digit 15 Coil and Valves 2 High ESP 100 Pa
E Standard DX Air Cooled Coil, EEV
3 High ESP 150 Pa
Digit 16 Enclosure Options 4 High ESP 200 Pa
1 Standard color black orange peel grain coating, ZP7021
Digit 24 Order Identier
Digit 17 Main Switch High Voltage Option
1-9 Factory Code
D Main Non-Locking Disconnect
Digit 25 Order Identier
A Dual power automatic Switching (interlock contactor)
0-9 Factory Code
The standard components are represented in ‘Bold Italic’ font in Table 1-1.
