Vertiv | SmartAisle2 | User Manual 5
Introduction
1.4. Environmental Requirements
1.4.1. Operating Conditions
The installation site of the SmartAisle2 should be such that the product is away from heat and environments
where there is a presence of easy-to-produce sparks, direct sunlight, corrosive gases, and organic solvents.
Operation Conditions are shown in Table 1-2:
Table 1-2 Operation Conditions
Parameters Values
Installation location
The maximum deviation during the product installation at ground level must be less than 0.5
mm/m; The maximum equivalent horizontal range of the indoor and outdoor air-conditioning is
50 m. Height dierence ∆H: -8m ≤ ∆H ≤ 30m
Application areas Large data centers, Mid-size data centers, Equipment & IT rooms
Ambient temperature
Indoor: 0 °C to 40 °C
Air Conditioners: -20 °C to +45 °C, such as a cryogenic assembly; minimum outdoor working
temperature is -34 °C
Environment humidity 5% RH ~ 90 % RH (30 °C, no condensation)
Altitude <1000 m, greater than 1000 m de-rating
Run power range 380 Vac to 415 Vac ± 10 %, 3 N
Note:
1: For detailed installation techniques for the air conditioning and power distribution equipment along with the
requirements, refer to the product’s user manual.
2: For the Air conditioning de-rating, contact the Vertiv local oice; for the cryogenic components, contact your local
Vertiv oice or the local dealer.
1.4.2. Storage Environment
The product storage environment is shown in Table 1-3.
Table 1-3 Storage Environment
Parameters Values
Storage Environment Room should be clean and clear of dust and debris
Environment humidity 5 % RH ~ 95 % RH (non-condensing)
Ambient temperature -33 °C to +70 °C
