Vertiv | SmartAisle2 | User Manual 28
Installation
2.5.4. Cabinet and Cabinet connections
For cabinet’s own connection between any two pieces of the cabinet and the cabinet, refer to the respective user
manuals meaning rack manual for rack-related connections or the CRV+ manual for the air conditioner.
2.5.5. Fastening the cabinet
Fastener is to be used between the cabinet and base followed by replacing the closure plate base of the cabinet.
2.6. Rack System Installation
The Rack System installation comprises the installation of the cabinet PDU and cabinet accessories. The cabinet
PDU hangs on the vertical cable management panel of the cabinet.
The accessories include a vertical cable management attachment plate, blind plates, trays, and windshield to
name a few. Refer to the corresponding user manual on the cabinet accessories for more details.
• For mounting the rack PDU, refer to the user manual of the IRS-P Series PDU.
