Installation
2.10. Supply and Distribution System Installation
Sl. No. Details of Equipment
1 Base
2 Server Cabinet
3 Network Cabinet
4 Access door
5 Top Plate
6 A/C Column
7 Distribution Cabinet
8 Strong wire passage groove
9 Power cable trunking; copper and fiber cable tray
10 Cabinet top wire groove
11 Control panel
In this section, the general layout of the electrical distribution cabinet and a rear equipment mounting method is
explained in detail.
