Vespa LX 50 Workshop Manual

Refitting the rear wheel
- Fit the wheel, tighten the nut to the prescribed
torque.
- Refit the cap and the split pin folding it correctly
as shown in the figure.
Locking torques (N*m)
Locking torque 137 ÷ 152 Nm
Swing-arm
Removal
Remove the swinging arm acting on the three
clamps shown in the figure.
Suspensions Vespa LX 50
SUSP - 104

Vespa LX 50 Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	49.9 cc
Fuel System	Carburetor
Front Brake	200 mm disc
Rear Brake	110 mm drum
Seat Height	785 mm
Fuel Tank Capacity	8.6 liters
Tires Front	110/70 - 11"
Tires Rear	120/70 - 10"
Length	1, 770 mm
Width	705 mm
Cooling System	Air cooled
Transmission	Automatic
Max Power	3.2 kW
Max Torque	4.2 Nm
