Vespa LX 50 Workshop Manual

This section is devoted to operations that can be carried out on the suspension.
Front
Removing the front wheel
- Remove the five Allen screws that fix the wheel
to the hub.
N.B.
BEFORE REMOVING THE WHEEL HUB, REMOVE THE
BRAKE CALLIPER.
Front wheel hub overhaul
- Remove the ball bearing check Seeger ring indi-
cated in the picture
Extract the ball bearing using the specific tool
Specific tooling
001467Y014 Pliers to extract ø 15-mm bearings
001467Y017 Bell for bearings, OD 39 mm
Suspensions Vespa LX 50
SUSP - 92

Vespa LX 50 Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	49.9 cc
Fuel System	Carburetor
Front Brake	200 mm disc
Rear Brake	110 mm drum
Seat Height	785 mm
Fuel Tank Capacity	8.6 liters
Tires Front	110/70 - 11"
Tires Rear	120/70 - 10"
Length	1, 770 mm
Width	705 mm
Cooling System	Air cooled
Transmission	Automatic
Max Power	3.2 kW
Max Torque	4.2 Nm
