Vespa LX 50 Workshop Manual

Refitting
- Install a new flywheel-side oil seal only with the
special tool's punch
The flywheel-side oil seal is recognised by its
smaller diameter
N.B.
THE USE OF THE SPECIFIC TOOL IS NOT COMPATIBLE
WITH THE FITTED WRENCH
Specific tooling
020340Y Flywheel and transmission oil seals
fitting punch
- Install a new transmission side oil seal using the
special tool with adapter ring.
The transmission-side oil seal is recognised by the
larger diameter
Specific tooling
020340Y Flywheel and transmission oil seals
fitting punch
Oil pump
Removal
- Remove the 2 screws shown in the figure
Engine Vespa LX 50
ENG - 88

Vespa LX 50 Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	49.9 cc
Fuel System	Carburetor
Front Brake	200 mm disc
Rear Brake	110 mm drum
Seat Height	785 mm
Fuel Tank Capacity	8.6 liters
Tires Front	110/70 - 11"
Tires Rear	120/70 - 10"
Length	1, 770 mm
Width	705 mm
Cooling System	Air cooled
Transmission	Automatic
Max Power	3.2 kW
Max Torque	4.2 Nm
