Vespa LX 50 Workshop Manual

Turn signal lights
TURN INDICATORS AND HORN
Specification
Desc./Quantity
1 Battery 12V - 4Ah
2 Main fuse 7,5A
3 Key switch
4 Magneto flywheel
5 Voltage regulator
6 Horn button
7 Horn
8 Indicators switch
9 Two (2) turn signal warning light bulbs 12V - 2W
10 4 Turn indicator bulbs 12V-10W
Checks and inspections
All the control operations of the system that entail
disconnecting cables (to check connections and
the devices making up the ignition circuit) must be
done with the engine off: if this is not done, the
controls might be irreparably damaged.
Electrical system Vespa LX 50
ELE SYS - 50

Vespa LX 50 Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	49.9 cc
Fuel System	Carburetor
Front Brake	200 mm disc
Rear Brake	110 mm drum
Seat Height	785 mm
Fuel Tank Capacity	8.6 liters
Tires Front	110/70 - 11"
Tires Rear	120/70 - 10"
Length	1, 770 mm
Width	705 mm
Cooling System	Air cooled
Transmission	Automatic
Max Power	3.2 kW
Max Torque	4.2 Nm
