Vespa LX 50 Workshop Manual

Rear handlebar cover
Undo the screws as shown in the figure and re-
move the handlebar rear section.
Instrument panel
Operate the 4 screws shown in the figure to re-
place the instrument panel.
Front handlebar cover
• Remove the 2 screws in the rear handlebar cover
and the screw under the headlamp.
• Pull up and detach the front handlebar cover,
disconnect the headlight assembly connections.
Chassis Vespa LX 50
CHAS - 114

Vespa LX 50 Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	49.9 cc
Fuel System	Carburetor
Front Brake	200 mm disc
Rear Brake	110 mm drum
Seat Height	785 mm
Fuel Tank Capacity	8.6 liters
Tires Front	110/70 - 11"
Tires Rear	120/70 - 10"
Length	1, 770 mm
Width	705 mm
Cooling System	Air cooled
Transmission	Automatic
Max Power	3.2 kW
Max Torque	4.2 Nm
