Vespa LX 50 Workshop Manual

When fitting the fork, lubricate with the steering
bearing tracks with the recommended grease.
Tighten the lower ring nut "A" and the upper ring
nut "B" to the specified torque
Recommended products
AGIP GREASE PV2 Grease for the steering
bearings, pin seats and swinging arm
White anhydrous-calcium based grease to protect
roller bearings; temperature range between -20 C
and +120 C; NLGI 2; ISO-L-XBCIB2.
Locking torques (N*m)
Steering lower ring nut 8 ÷ 10 Upper steering
ring nut 35 ÷ 40
Front shock absorber
Vespa LX 50 Suspensions
SUSP - 99

Vespa LX 50 Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	49.9 cc
Fuel System	Carburetor
Front Brake	200 mm disc
Rear Brake	110 mm drum
Seat Height	785 mm
Fuel Tank Capacity	8.6 liters
Tires Front	110/70 - 11"
Tires Rear	120/70 - 10"
Length	1, 770 mm
Width	705 mm
Cooling System	Air cooled
Transmission	Automatic
Max Power	3.2 kW
Max Torque	4.2 Nm
