Vespa LX 50 Workshop Manual

Handlebar components
HANDLEBAR COMPONENTS
Code
Action Duration
1 004066 Driving mirror - Replacement
2 002037 Brake or clutch lever - Replacement
3 002071 Left hand grip - Replacement
4 003001 Handlebar - Replacement
5 005017 Stop switch - Replacement
6 002024 Front brake pump - Removal and Re-
fitting
7 002054 Throttle or splitter transmission com-
plete - Replacement
8 002060 Complete throttle control - Replace-
ment
9 004162 Mirror support and/or brake pump fit-
ting U-bolt - Replacement
10 002059 Right hand grip - Replacement
Vespa LX 50 Time
TIME - 149

Vespa LX 50 Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	49.9 cc
Fuel System	Carburetor
Front Brake	200 mm disc
Rear Brake	110 mm drum
Seat Height	785 mm
Fuel Tank Capacity	8.6 liters
Tires Front	110/70 - 11"
Tires Rear	120/70 - 10"
Length	1, 770 mm
Width	705 mm
Cooling System	Air cooled
Transmission	Automatic
Max Power	3.2 kW
Max Torque	4.2 Nm
