Vespa LX 50 Workshop Manual

tightening torque 5 ÷ 6.5 Nm
Disc Inspection
Specific tooling
020335Y Magnetic support for dial gauge
Characteristic
Max oscillation allowed
0.1 mm.
Front brake pads
Removal
- Pads must be replaced when the friction material
thickness reaches the wear limit.
- To replace:
remove the protection cover, the bolt and the leaf
spring. Slide off the pads and replace them once
the plungers are down. Carry out these operations
in reverse order to fit.
CAUTION
BEFORE USING THE BRAKE, OPERATE THE LEVER A
FEW TIMES.
Front
-Once the bleed valve is closed, fill the system with
brake liquid to the maximum level.
-Undo the bleed screw.
-Apply the tube of the special tool to the bleed
screws.
When bleeding it is necessary to fill the oil tank in
continuation while working with a MITYVAC pump
on the bleed screws until no more air comes out of
the system.
Braking system Vespa LX 50
BRAK SYS - 110

Vespa LX 50 Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	49.9 cc
Fuel System	Carburetor
Front Brake	200 mm disc
Rear Brake	110 mm drum
Seat Height	785 mm
Fuel Tank Capacity	8.6 liters
Tires Front	110/70 - 11"
Tires Rear	120/70 - 10"
Length	1, 770 mm
Width	705 mm
Cooling System	Air cooled
Transmission	Automatic
Max Power	3.2 kW
Max Torque	4.2 Nm
