Vespa LX 50 Workshop Manual

Level indicators and enable signals section
START PERMISSIVE BUTTONS AND LEVEL INDICATORS
Specification
Desc./Quantity
1 Magneto flywheel
2 Voltage regulator
3 Key switch
4 Main fuse 7,5A
5 Brake light filament 12V - 21W
6 Front and rear brake light button
7 Start up button
8 Starter motor
9 Remote starter switch
10 Battery 12V - 4Ah
11 Low oil warning light 12V - 1.2W
12 Oil level sender
13 Low fuel warning light 12V - 1.2W
14 Fuel gauge
15 Fuel level sender
Vespa LX 50 Electrical system
ELE SYS - 49

Vespa LX 50 Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	49.9 cc
Fuel System	Carburetor
Front Brake	200 mm disc
Rear Brake	110 mm drum
Seat Height	785 mm
Fuel Tank Capacity	8.6 liters
Tires Front	110/70 - 11"
Tires Rear	120/70 - 10"
Length	1, 770 mm
Width	705 mm
Cooling System	Air cooled
Transmission	Automatic
Max Power	3.2 kW
Max Torque	4.2 Nm
