Vespa LX 50 Workshop Manual

Secondary air box
SECONDARY AIR HOUSING
Code
Action Duration
1 001164 Crankcase secondary air connection
- Replacement
2 001161 Secondary air filter - Replacement /
Cleaning
3 001162 Secondary air housing - Replace-
ment
4 001163 Muffler secondary air connection -
Replacement
5 001165 Secondary air reed - Replacement
Vespa LX 50 Time
TIME - 159

Vespa LX 50 Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	49.9 cc
Fuel System	Carburetor
Front Brake	200 mm disc
Rear Brake	110 mm drum
Seat Height	785 mm
Fuel Tank Capacity	8.6 liters
Tires Front	110/70 - 11"
Tires Rear	120/70 - 10"
Length	1, 770 mm
Width	705 mm
Cooling System	Air cooled
Transmission	Automatic
Max Power	3.2 kW
Max Torque	4.2 Nm
