Vetus M2.13 - Torque Wrench Settings

122
10 Technical data
Torque wrench settings
M2.13 M2.18 M3.29 M3.28 SOLAS
Screw connection Thread Wrench Size Torque
Nm (kgm)
(ft.lbf)
Cylinder head bolt M10 14 78 ±5 (8 ±0.5)
(58 ±3.5)
Cilinder head bolt M8 12 25 ±5 (2.5 ±0.5)
(18 ±3.5)
Connecting rod nut M8 14 33 ±1.5 (3.35 ±0.15)
(24 ±1)
Fly wheel bolt M10 17 88 ±5 (9 ±0.5)
(65 ±3.5)
Crank shaft pulley nut M16 24 108 ±10 (11 ±1.0)
(80 ±7)
Main bearing cap bolt M10 17 52 ±2.5 (5.25 ±0.25)
(38 ±2)
Rocker stay bolt M8 12 18 ±3.5 (1.85 ±0.35)
(13 ±2.5)
Valve cover nut M6 10 6 ±1 (0.6 ±0.1)
(4.5 ±0.8)
Nozzle holder M20 21 54 ±5 (5.5 ±0.5)
(40 ±3.5)
Fuel leak oil pipe nut M12 17 25 ±5 (2.5 ±0.5)
(18 ±3.5)
Nozzle retaining nut M16 21 37 ±2.5 (3.75 ±0.25)
(27 ±2)
Fuel injection pipe nut M12 17 29 ±5 (3.0 ±0.5)
(21 ±3.5)
Delivery valve holder M16 17 36 ±2 (3.7 ±0.2)
(26 ±1.5)
Injection pump hollow screw M10 14 12 ±2.5 (1.25 ±0.25)
(9 ±2)
Injection pump air vent screw M6 10 6 ±1 (0.6 ±0.1)
(4.5 ±0.8)
Solenoid lock nut M30 36 44 ±5 (4.5 ±0.5)
(32 ±3.5)
Temperature switch M16 19 22.5 ±4 (2.3 ±0.4)
(16.5 ±3)
Oil lter M20 — 12 ±1 (1.2 ±0.1)
(9 ±0.8)
Oil pressure switch PT1/8 26 10 ±2 (1 ±0.2)
(7 ±1.5)
Pressure relief valve M18 22 44 ±5 (4.5 ±0.5)
(32 ±3.5)
Oil drain plug M18 19 54 ±5 (5.5 ±0.5)
(40 ±3.5)
Glow plug M10 12 17.5 ±2.5 (1.75 ±0.25)
(13 ±2)
