Vetus M2.13 - Engine Oil Level Check

OIL OIL
48
6 Maintenance
Checking engine oil level
Daily, before starting.
1 Check oil level
• Turn the engine o.
The dipstick is located on the starboard side
of the engine.
2 Oil level
The oil level must be at or near the upper
mark on the dipstick
[1]
.
• If necessary top up with the same brand
and type of oil.
3 Topping up oil
The oil lling cap is on top of the the valve
cover,.
A second oil lling cap is located at the distru-
bution cover, see page 20.
[1]
The dierence between the
two oil level marks is:
VD00155 VD00982 VD00976
litres Imp. pt US pt
M2 : 1.25 2.2 2.6
M3 : 1.3 2.3 2.7
M4 : 1.8 3.2 3.8
