1 2
70
6 Maintenance
Checking valve clearance
Every 500 operating hours.
37 Checking / adjusting valve clearance
Checking the valve clearance must be done
with a cold engine, that is an engine which
did not run for at least 6 hours.
38 Remove upper cover
• Close the sea cock.
• Disconnect the hoses (1) and (2).
• Remove the 4 bolts and remove the upper
cover.
39 Remove the V-belt protection cover
• Loosen the the screws -the screws can be
loosened without tools and they have anti-
loss rings- and remove the V-belt protec-
tion.
note
After checking / adjusting the valve clearance
re-install the V-belt protection and the upper
cover and re-connect the hoses.
13
VD02030
VD02036
6
