Vetus M2.13 - Identification of Engine Parts M2, M3

1 2 3 4 5 6 7 8
9 10 11 12
12
2 Introduction
Identication of engine parts M2, M3
VD02022
1 Calorier connection, engine ‘IN’
2 Calorier connection, engine ‘OUT’
3 Cooling system air bleed nipple / Con-
nection for extra expansion tank (Keel
cooling model only)
4 Oil ller cap
5 Filler cap for cooling system
6 Expansion tank
7 Heat exchanger
8 Cooling system drain plug
9 V-belt
10 Alternator
11 Starter motor
12 Exhaust injection bend ø 40 mm
