2 Introduction
Identication of engine parts M2, M3
VD02023
13 Airvent connection
14 Water separator/Fuel lter
15 Water separator/fuel lter air bleed
nipple
16 Fuse
17 Fuel lift pump
18 Connection electrical system
19 Fuel supply pipe connection ø 8 mm
20 Air inlet silencer / Air lter
21 Oil dipstick
22 Connection for throttle push-pull cable
23 Gearbox ller cap
24 Water separator/fuel lter drain plug
25 Gearbox
26 Fuel return pipe connection ø 8 mm
27 Oil lter
28 Manual operation of electric stop
29 Raw water inlet ø 20 mm
30 Raw water pump
31 Fuel pump air bleed nipple
