Single lever control
handle for two engines
Single lever control
handle for 1 engine
neutral
gearbox reverse gearbox forward
forward throttlereverse throttle
19
2 Introduction
Control lever
6 Operating lever
Operating lever for 1 or 2 engines. The control lever works as shown in the dia-
gram.
Starting from neutral put the engine in ahead
or astern by moving the lever 35° forwards or
backwards.
The throttle lever operates at an angle of 60°
forwards and 60° reverse.
VD00788
