Vetus M2.13 - Page 20

5
3
7
8
6
13
9
1 2
5
3
7
8
6
4
14
1 2
18
8 Indicator light pre-heating
9 Warning light gearbox low oil pressure
[1]
13 Warning light second alternator
14 Warning light general
1 Tachometer/Operating hours counter
2 Voltmeter
3 Starter pre-heat switch/lock
4 Warning light high raw water temperature
5 Warning light low oil pressure
6 Warning light high coolant temperature
7 Warning light battery charging
2 Introduction
Control panels,
option
Panel, model MP22
for keel cooled engines with second alternator only
Panel, model MPA22
[1]
This is an option, not tted as standard.
VD00630 VD00952
