17 18 19 20 21 22 23 24 25 26
27 28 29 30 31 32 33 34 35
15
2 Introduction
Identication of engine parts M4
VD00972
17 Exhaust injection bend ø 50 mm
18 Water separator/Fuel lter
19 Water separator/fuel lter air bleed
nipple
20 Fuse
21 Fuel lift pump
22 Connection electrical system
23 Fuel supply pipe connection ø 8 mm
24 Air inlet silencer / Air lter
25 Oil dipstick
26 Fuel pump air bleed nipple
27 Gearbox
28 Gearbox ller cap
29 Water separator/fuel lter drain plug
30 Gearbox oil dipstick
31 Fuel return pipe connection ø 8 mm
32 Cooling system drain plug
33 Oil lter
34 Manual operation of electric stop
35 Connection for throttle push-pull cable
