15.3 POSITION AND HEIGHT OF NEEDLE BAR THREAD TAKE UP
The eye bar is connected to the needle bar as follows:
Position the needle bar in bottom dead point .
Needle bar eye in line
with upper fusion side
Needle bar eye in line
with upper fusion side
