VI.BE.MAC.S.p.A. 3022LV
15.11 ADJUSTING THE CLAMP HEIGHT:
The clamp should be adjusted so that it comes up through the 1 mm needle plate. In order to make this adjustment, use a
screwdriver to loosen the screw (1) that holds the clamp itself in place and position it as illustrated below. Then adjust the pin (2)
that acts as a rebate.
2
1mm
3
1
15.11.1 CLAMP POSITION WITH RESPECT TO THE NEEDLE PLATE.
The clamp should be positioned in the very centre of the needle plate space.
In order to make this adjustment, loosen the nuts (3) illustrated above.
15.12. ADJUSTING THE LOWER THREAD PULLER.
The thread puller should be adjusted so that when the crochet hooks are as far forward as they can go and are about to return, the
thread puller lever starts to pull upwards.
Page 27
3022-029
Crochet hook POSITION completely
BACK FORWARD
