Maintenance
62
Inspection - oil service
Every day
The oil level for the cutterbar is checked as follows:
Place the machine on a level surface.
Lower the cutterbar to the ground.
Check that the cutterbar is horizontal in the direction shown using
a spirit level or similar tool.
If the cutterbar is not horizontal in the direction of travel, carry out the
following:
Correct the length of the top link.
Locate the oilplug on the cutterbar and remove it.
• With warm oil: Wait approximately 3 minutes
• With cold oil: Wait approximately 15 minutes.
• Check the oil level as shown and refill if necessary.
»Lubricants« page 109
»Maintenance intervals« page 56
Fit the oilplug.
