Maintenance
88
Bevel gear - cutterbar
Every season
Changing oil
• Oil amount when changing oil:
»Maintenance intervals« page 56
The oil is changed as follows:
Pull and release the lock.
Open the guard around the machine's cutterbar.
Use a suitable tool and remove the guard around the cutterbar's
transmission.
Remove the oilplug.
Let the oil flow into a suitable container.
Allow the last of the oil to drip out of the transmission for approx.
10 - 15 minutes.
Fit the oilplug.
Litre
(approx.)
Pints (US)
(approx.)
Pints (Imp.)
(approx.)
1.0 2.1 1.8
