1. POWER INDICATOR
2. POWER SWITCH
3. TAKE BAR (FOR MANUAL TRANSITIONS)
4. AUTO-TAKE, AUTO-TAKE SPEED, AND VIDEO
FREEZE BUTTONS
5. TRANSITION EFFECT BUTTONS
6. AUDIO/VIDEO SELECTOR AND INDICATOR
7. INPUT EFFECTS (MOSAIC, STROBE, ETC.)
BUTTON
8. 4-INPUT SWITCHER CONTROLS, INDICATORS
9. BORDER AND BACKGROUND COLOR BUTTONS
10. TRANSITION-EFFECT SELECTION BUTTONS,
ARROW KEYPAD
11. PREVIEW MONITOR DISPLAY SWITCH
12. DEMO BUTTON
13. SETUP SCREEN BUTTON
14. SEQUENCER “LEARN” BUTTON
15. CHROMA KEY BUTTON
16. COMPOSE BUTTON
17. SHIFT
18. NEXT-SOURCE SELECTORS
19. ERGONOMIC PALM REST
CONTROLS
INPUT
F/X
PLAY
(
AUTO TAKE
)
BACK
COLOR
BORDER
COLOR
AUDIO
VIDEO
ZOOM /
P-IN-P
FLIP
WIPE
FADE /
DISSOLVE
COMPOSE
CHROMA
KEY
DEMO
SETUP
LEARN
DISPLAY
CUT ➔
ABCD
COLOR
7
4
0
8
5
9
6
123
SPEEDFREEZE
SHIFT
ABCD
COLOR
CUT ➔ CUT ➔ CUT ➔ CUT ➔
VIDEONICS
OK
REVERSE
DIGITAL VIDEO MIXER
23 456 7 9 10 11
12
13
14
15
16
17
18
19
81
REAR PANEL
PREVIEW
OUT
POWER
HEAD
PHONE
IN 4
IN 1
IN 2
OUT
IN 3
CONTROL
(
GPI
)
POWER
CONTROL HEADPHONE PREVIEW V — IN 4 — S RLV S RLV S
IN 3
OUT
IN 2
IN 1
V
LRV
LRVLRV
LRV
A
B
EC
D
FG H I
A. INPUT 1
B. INPUT 2
C. INPUT 3
D. INPUT 4 (VIDEO ONLY)
E. OUTPUT
F. PREVIEW/CONTROL SCREEN OUTPUT
(COMPOSITE VIDEO)
G. HEADPHONE OUT
H. CONTROL INPUT (GPI TRIGGER)
I. POWER
INPUTS 1-3 AND MAIN OUTPUT INCLUDE JACKS FOR S-VIDEO, COMPOSITE (RCA-STYLE) VIDEO, AND RIGHT
AND LEFT AUDIO. JACKS ARE LABELED UPSIDE DOWN AT TOP OF PANEL TO FACILITATE CONNECTIONS
WITHOUT TURNING UNIT AROUND.
