VIDEONICS DIGITAL VIDEO MIXER PAGE 83
Chapter
23 •23 • Effects
List
Terms and Abbrevia-
tions
(A): The CURRENT source (the one on the screen
before the transition begins).
(B): The NEXT source (the one on the screen after
the transition is complete).
Dissolve: One image fades away as another fades
in.
Wipe: A wipe is a simple window or boundary that
reveals the underlying video. The video image nei-
ther moves nor changes size.
Slide: A slide leaves the video full size but the
picture moves with the transition.
Comp., Exp.: (Compress,Expand): The video is
resized to fit in the window — generally the entire
picture will be scaled to fill the window.
H, V: (Horizontal, Vertical): These refer to the di-
rection the transition moves. For example, a V wipe
is a horizontal line that moves vertically up or
down the screen. When the effect runs in the for-
ward (non-reversed) direction, vertical transitions
move down the screen and horizontal transitions
move from left to right, unless otherwise indicated.
CW: Clockwise • CCW: Counter clockwise
L: Left • R: Right • Ctr: Center • T: Top • B:
Bottom
TLC: Top Left Corner • TRC: Top Right Corner •
BLC: Bottom Left Corner • BRC: Bottom Right
Corner
“;” divides multi-step transitions. “/” indicates
two actions that occur at once.
* Transitions with * always use fixed direction
when performed from frozen picture. They are not
affected by REVERSE button.
# Transitions with # operate differently when per-
formed from a frozen picture. Simpler effects are
automatically substituted.
“Top 30” Effects
The “Top 30” symbols, numbers 0-29, are the
ones that appear on the PREVIEW screen when you
first turn the Mixer on. They represent 30 com-
monly used effects. They are duplicated elsewhere
in the effects list, near related effects. The “=”
column shows the effect’s other location.
NO. = DESCRIPTION
0 - Cut
1 160 Dissolve
2 30 H Wipe
3 70 V Wipe
4 40 H Curtain Wipe (B) from Ctr to full
5 81 V Curtain Exp. (B) from Ctr to full
6 35 H Slide (A)/Exp. (B)
7 38 H Slide (A)/Slide (B)
8 74 V Comp. (A)/Exp. (B)
9 78 V Slide (A)/Slide (B)
10
#
56
#
H Slide (A) out L; Slide (B) in from L
11* 66* H Comp. (A) R to 1/2 screen slice;
Slide to L; slide under Ctr line
12 171 Ctr Exp. (B)
13 161 Ctr Exp. & Dissolve (B)
14
#
188
#
Comp. (A) to lower R of (B); Exp. (B)
15
#
184
#
H Comp. (A) alongside (B) in mo-
tion; Exp. (B)
16 180 Comp. (A) to 1/2; roll R to (B); Exp.
17 114 Slide in slice (B) from L at T; Wipe
slice to full
18 227 V Comp. (A) to Ctr slice; H collapse
slice to Ctr point
19 212 Butterfly from T L/random proportion
20 210 Ctr Exp. (B) with 2 flips
21 222 Ctr Comp. (A); swing back; out B
22 193 Bounce off edges/Wipe
23 190 Bounce in from T
24* 200* Comp. (A) to T; CW spiral out to T
25* 208* Comp. (A); CW spiral to Ctr
26
#
221
#
Mosaic Zoom
27 216 Random Sizes & Flips (B)
28 237 Luminance Key 1
29 234 Checkerboard w/middle dissolve
