PAGE 76 VIDEONICS DIGITAL VIDEO MIXER
Chapter
21 •21 • Specifica-
tions
BASIC FEATURES
4-input switcher, digital frame synchronizer and
special effects mixer with dual time base
corrector.
EFFECTS
Video: 210 dissolves, wipes, slides, compress/
expand, fly-in, flips, zooms, luminance key, more
(see list). Manual or automatic at 10 speeds.
Input effects include black and white, negative
(black and white and/or color), horizontal and
vertical flip, mosaic, strobe, film-look strobe,
paint/posterization, solarization. Can be
combined.
Special effect modes include compose, picture-
in-picture, chroma key, stop action (snapshot).
Audio: Mix, fade, audio-follows-video or
separate control.
COLOR GENERATORS
2 (background and border), 1440 colors.
OTHER FEATURES
LEARN mode stores up to 25 transition effects.
Preview display shows all four inputs.
Color bar generator, black burst, color genera-
tors.
Field freeze.
GENERAL SPECIFICATIONS
Power: 12 VAC, 1A. 120 VAC, 60 Hz adapter
included in US/Canada. (Other supplies available
in other areas.)
FCC/UL/CSA approved (non-US/Canada
versions meet local regulatory standards).
Dimensions: 12 x 9.5 x 3.9" (300 x 165 x 99
mm).
Weight: 4 lbs. (1.8 kg).
Ambient temperature: 32-104°F (0-40°C).
Ambient humidity: Less than 90%.
INPUTS
VIDEO: 4 x S-video (Y/C): Y=1 Vp-p, C=0.30 Vp-
p, 75-ohm, 4-pin mini-DIN connectors.
4 x composite (RCA): 1.0 Vp-p 75-ohm, RCA
connectors.
AUDIO: 6 x RCA connectors, 15 k ohms.
GPI: Mini-jack.
OUTPUTS
VIDEO (PREVIEW and MAIN): 2 x 1.0 Vp-p, 75
ohm, RCA connectors.
S-VIDEO (MAIN): Y=1.0 Vp-p, C=0.3 Vp-p; 75
ohm, 4-pin mini-DIN connector.
AUDIO (L and R): 1 k ohms, RCA connectors.
HEADPHONE: Stereo jack, 8-100 ohms, mono
signal.
VIDEO PERFORMANCE
Meets FCC broadcast specifications.
Digital conversion: 13.5 MHz, 4:2:2, 8-bit
quantization, 4 X subcarrier oversampling.
Dual-field infinite-window time base corrector.
Time base meets RS-170A standard.
Compatible with all NTSC videos sources and
tape formats. (PAL version available.)
Gain: Unity.
S/N Ratio: 56 dB
Resolution: 5.0 MHz
AUDIO PERFORMANCE
Frequency response: 20 Hz-20 kHz, ± 3 dB.
S/N ratio: 56 dB.
