Viessmann VITOCAL Series - Page 12

Type AWO/AWO-E/AWO-E-AC 201.A10 201.A13 201.A16
Heating water (secondary circuit)
Minimum flow rate l/h 1400 1400 1400
Minimum volume in the heating system, cannot be fitted
with shut-off devices
l 50 50 50
Max. external pressure drop (RFH) at minimum flow rate mbar 500 500 500
kPa 50 50 50
Max. flow temperature °C 60 60 60
Outdoor unit electrical values
Rated voltage, compressor 3/N/PE 400 V/50 Hz
Max. operating current, compressor A 8.7 8.7 8.7
Cos φ 0.96 0.96 0.96
Starting current, compressor A 15 15 15
Fuse rating B16 A B16 A B16 A
IP rating IP X4 IP X4 IP X4
Indoor unit electrical values
Heat pump control unit/PCB
– Rated voltage, control unit/PCB 1/N/PE 230 V/50 Hz
– Power supply fuse rating 1 x B16A 1 x B16 A 1 x B16 A
– Internal fuse 6.3 A (slow)/250 V
Instantaneous heating water heater
– Type AWO-E/AWO-E-AC:
Factory-fitted
– Type AWO:
Accessories
– Rated voltage 1/N/PE 230 V/50 Hz
or
3/N/PE 400 V/50 Hz
– Heating output kW 9 9 9
– Power supply fuse rating 3 x B16A 3 x B16 A 3 x B16 A
Max. power consumption
Fan W 2 x 45 2 x 45 2 x 45
Outdoor unit kW 5.13 5.13 5.15
Secondary pump (PWM) W 60 60 60
– Energy efficiency index EEI ≤ 0.2 ≤ 0.2 ≤ 0.2
Control unit/PCB, outdoor unit W 15 15 15
Control unit/PCB, indoor unit W 10 10 10
Control unit/PCB power, indoor unit W 1000 1000 1000
Refrigerant circuit
Refrigerant R410A R410A R410A
– Refrigerant charge kg 2.40 2.40 2.40
–
Global warming potential (GWP)
*3
1924 1924 1924
– CO
2
equivalent t 4.6 4.6 4.6
Compressor (hermetically sealed) Type Scroll Scroll Scroll
– Oil in compressor Type 3 MAF POE 3 MAF POE 3 MAF POE
– Quantity of oil in compressor l 1.17 1.17 1.17
Permissible operating pressure
– High pressure side bar 43 43 43
MPa 4.3 4.3 4.3
– Low pressure side bar 28 28 28
MPa 2.8 2.8 2.8
Outdoor unit dimensions
Total length mm 546 546 546
Total width mm 1109 1109 1109
Total height mm 1377 1377 1377
Indoor unit dimensions
Total length mm 370 370 370
Total width mm 450 450 450
Total height mm 880 880 880
Total weight
Outdoor unit kg 153 153 153
Indoor unit
– Type AWO kg 40 40 40
– Type AWO-E/AWO-E-AC kg 41 41 41
Permissible operating pressure, secondary side bar 3 3 3
MPa 0.3 0.3 0.3
*3
Based on the Fifth Assessment Report of the Intergovernmental Panel on Climate Change (IPCC)
Vitocal 200-A
(cont.)
