Viessmann VITOCAL Series - Page 78

Vitocell 100-V, type CVA, 500 l capacity
h
a
b
n
o
SPR
l
k
m
BÖ
VA
WW
Z
HR
KW/E
g
f
e
d
c
HV/SPR
b
BÖ Inspection and cleaning aperture
E Drain
HR Heating water return
HV Heating water flow
KW Cold water
SPR Cylinder temperature sensor of the cylinder temperature con-
troller or temperature controller (internal diameter of sensor
well 16 mm)
VA Protective magnesium anode
WW DHW
Z DHW circulation
Dimensions
Cylinder capacity l 500
Length (7)
a mm 859
Width b mm 923
Height c mm 1948
d mm 1784
e mm 1230
f mm 924
g mm 349
h mm 107
k mm 455
l mm
7 100
m mm 422
Excl. thermal insulation n mm 837
Excl. thermal insulation o mm
7 650
Installation accessories
(cont.)
