Type CVBB CVB CVB CVBB CVBB
Cylinder capacity
(AT: Actual water capacity)
l 300 400 500 750 950
Internal indirect coil Top Bot-
tom
Top Bot-
tom
Top Bot-
tom
Top Bot-
tom
Top Bottom
Entire weight with thermal insu-
lation
kg 166 167 205 320 390
Total weight in operation incl.
immersion heater
kg 468 569 707 1072 1342
Heating surface
m
2
0.9 1.5 1.0 1.5 1.4 1.9 1.6 3.5 2.2 3.9
Connections
Upper indirect coil (male thread) R 1 1 1 1 1
Lower indirect coil (male thread) R 1 1 1 1¼ 1¼
Cold water, DHW (male thread) R 1 1¼ 1¼ 1¼ 1¼
DHW circulation (male thread) R 1 1 1 1¼ 1¼
Immersion heater (female
thread)
Rp 1½ 1½ 1½ – –
Energy efficiency class B B B – –
Information regarding the upper indirect coil
The upper indirect coil is designed for connection to a heat genera-
tor.
Information regarding the lower indirect coil
The lower indirect coil is designed for connection to solar collectors.
To install the cylinder temperature sensor, use the threaded elbow
with sensor well included in standard delivery.
Information regarding continuous output
When designing systems with the specified or calculated continuous
output, select a matching circulation pump. The stated continuous
output is achieved only if the rated boiler heating output is ≥ the con-
tinuous output.
Note
The versions with 300 and 400 l capacity are also available in white
as Vitocell 100-W.
Installation accessories
(cont.)
