Table for selection according to continuous output
Continuous output for DHW
heating
Continuous output for DHW heating
from 10 to 60 °C from 10 to 45 °C
Flow temperature 90 °C 80 °C 70 °C
1
90 °C 80 °C 70 °C 60 °C 50 °C
Horizontal DHW
cylinders
Vitocell 100-H, 130 l, type CHA 27 kW 20 kW 14 kW 28 kW 23 kW 19 kW 14 kW —
Vitocell 100-H, 160 l, type CHA 32 kW 24 kW 17 kW 33 kW 28 kW 22 kW 16 kW —
Vitocell 100-H, 200 l, type CHA 38 kW 29 kW 19 kW 42 kW 32 kW 26 kW 18 kW —
Vitocell 300-H, 160 l, type EHA 28 kW 23 kW 15 kW 32 kW 28 kW 20 kW 14 kW —
Vitocell 300-H, 200 l, type EHA 33 kW 25 kW 17 kW 41 kW 30 kW 23 kW 16 kW —
Vitocell 300-H, 350 l, type EHA 70 kW 51 kW 34 kW 80 kW 64 kW 47 kW 33 kW —
Vitocell 300-H, 500 l, type EHA 82 kW 62 kW 39 kW 97 kW 76 kW 55 kW 38 kW —
DHW cylinders
for wall mounted
boilers
Vitocell 100-W, 120 l, type CUG — — — — 24 kW — — —
Vitocell 100-W, 150 l, type CUG — — — — 24 kW — — —
Vitocell 100-V, 160 l, type CVA 36 kW 28 kW 19 kW 40 kW 32 kW 25 kW 9 kW —
3
Vitocell 100-V, 200 l, type CVA 36 kW 28 kW 19 kW
2
40 kW 32 kW 17 kW 9 kW —
Vertical DHW cyl-
inders
Vitocell 100-V, 300 l, type CVA 45 kW 34 kW 23 kW 53 kW 44 kW 23 kW 18 kW —
Vitocell 100-V, 500 l, type CVA 53 kW 44 kW 33 kW 70 kW 58 kW 32 kW 24 kW —
Vitocell 100-V, 750 l, type CVA 102 kW 77 kW 53 kW 123 kW 99 kW 53 kW 28 kW —
Vitocell 100-V, 1000 l, type CVA 121 kW 91 kW 61 kW 136 kW 111 kW 59 kW 33 kW —
Vitocell 100-V, 390 l, type CVW 98 kW 78 kW 54 kW 109 kW 87 kW 77 kW 48 kW 26 kW
Vitocell 300-V 130 l, type EVA 32 kW 25 kW 16 kW 37 kW 30 kW 22 kW 13 kW 9 kW
Vitocell 300-V 160 l, type EVA 36 kW 28 kW 19 kW 40 kW 32 kW 24 kW 15 kW 10 kW
Vitocell 300-V 200 l, type EVA 57 kW 43 kW 25 kW 62 kW 49 kW 38 kW 25 kW 12 kW
Vitocell 300-V, 200 l, type EVI 63 kW 48 kW 29 kW 71 kW 56 kW 44 kW 24 kW 13 kW
Vitocell 300-V, 300 l, type EVI 82 kW 59 kW 41 kW 93 kW 72 kW 52 kW 30 kW 15 kW
Vitocell 300-V, 500 l, type EVI 81 kW 62 kW 43 kW 96 kW 73 kW 56 kW 37 kW 18 kW
Dual mode DHW
cylinders
A
Vitocell 100-U, 300 l, type CVUA 23 kW 20 kW 15 kW 31 kW 26 kW 20 kW 15 kW 11 kW
Vitocell 100-B, 300 l, type CVB 23 kW 20 kW 15 kW 31 kW 26 kW 20 kW 15 kW 11 kW
Vitocell 100-B, 400 l, type CVB 36 kW 27 kW 18 kW 42 kW 33 kW 25 kW 17 kW 10 kW
Vitocell 100-B, 500 l, type CVB 36 kW 30 kW 22 kW 47 kW 40 kW 30 kW 22 kW 16 kW
Vitocell 300-B, 300 l, type EVB 74 kW 54 kW 35 kW 80 kW 64 kW 45 kW 28 kW 15 kW
Vitocell 300-B, 500 l, type EVB 74 kW 54 kW 35 kW 80 kW 64 kW 45 kW 28 kW 15 kW
Freshwater mod-
ule
Vitotrans 353, type PBS, type PZS 126 kW 102 kW 74 kW 92 kW 92 kW 92 kW 73 kW 44 kW
Vitotrans 353, type PBM, type PZM 203 kW 169 kW 129 kW 158 kW 158 kW 155 kW 121 kW 79 kW
Vitotrans 353, type PBL 273 kW 228 kW 176 kW 214 kW 214 kW 208 kW 163 kW 108 kW
1 - 3
Selection example
A
Upper indirect coil
Selecting the cylinder type
(cont.)
